| 输入: | 1 复合视频, 1Vpp/75Ω BNC ; 2 平衡式音频 +4dBu/600Ω 接线端子; |
| 输出: | 1 复合视频, 1Vpp/75Ω BNC; 2 平衡式音频 +4dBu/600Ω 接线端子; |
| INSERTION LOSS: | 0.8dB (video). |
| 最大输出电平: | 视频: 4Vpp / 75Ω; 音频: +26dBu |
| 带宽(-3DB): | 视频: <10Hz to 5.8MHz; -3dB 音频: 20Hz to 20kHz |
| DIFF. GAIN: | 0.05% |
| DIFF. PHASE: | 0.05 Deg |
| K-FACTOR: | <1.2% |
| S/N RATIO: | VIDEO: 73dB AUDIO: -83dBu @+4dBu/1000Hz |
| 控制: | 开关 |
| VIDEO TILT: | 0.1% @ Pulse & Bar |
| VIDEO NON LINEARITY: | 0.1% |
| 耦合: | 视频: Transformer; 音频: Transformer |
| 音频总体谐波损耗+噪音: | 0.025% @+4dBu/1000Hz |
| 尺寸: | 12.1cm x 7.2cm x 3cm (4.77” x 2.85” x 1.2”) W, D, H |
| 重量: | 0.34 kg. (0.75lbs.) approx. |
| 附件: | 安装件 |
| OPTIONS: | RK-3TR 19" rack adapter. |
