| 输入: |
1 复合视频 - 1 Vpp / 75Ω on a BNC connector; 1 YC - 1 Vpp / 75Ω (Y), 0.3Vpp / 75Ω on a 4p connector; 1 分量 - Y/R-Y/B-Y (1Vpp/0.7Vpp/0.7Vpp) /75Ω (or RGB/S) on BNC connectors; 1 SYNC (Genlock): Looped 75Ω / Hi-Z on BNC connectors. |
| 输出: |
1 复合视频 - 1 Vpp / 75Ω on a BNC connector; 1 YC - 1 Vpp / 75Ω (Y), 0.3Vpp / 75Ω on a 4p connector; 1 分量 - Y/R-Y/B-Y (1Vpp/0.7Vpp/0.7Vpp) /75Ω (or RGB/S) on BNC connectors. |
| 视频标准: | PAL-B/D/G/H/I/M/N, NTSC-3.58/4.43, SECAM |
| 数字解析: | 10 bits |
| 带宽(-3DB): | 0.5dB to 5MHz, Fully Loaded |
| 微分增益: | 1% |
| 微分相位: | 1% |
| K-因子: | 0.4% |
| 信噪比: | 60dB |
| 亮度非线性: | 1% |
| 色度 / 亮度延迟: | <15ns |
| 存储: | 可预存 16 个切换设置 |
| 控制: | 前面板和RS-232: 对比度, 亮度, 视频增益, 颜色, 色调, H/V sharpness, SCH phase, delay, H/V shift; R, G, B, R-Y, B-Y level; 分屏 (process to bypass); freeze; 面板锁定. |
| 电源: | 通用的, 100-240VAC, 50/60Hz |
| 尺寸: | 19 inch (W), 7 inch (D), 1U (H) rack mountable |
| 重量: | 2.6 kg. (5.7 lbs.) approx. |
| 附件: | 电源线, 适配器 |
