| Maximum Output Current: | 15 amps, 120 VAC (Thermal breaker) |
| Line Cord: | 14AWGx3, 10 feet, black, fixed, NEMA 5-15P plug |
| AC Receptacles: |
• Convenience Outlet (Front Panel) 1 Un-switched NEMA 15-5R • Rear Panel Outlets: 2 Un-switched NEMA 5-15R (1 duplex), • 6 Sequenced NEMA 5-15R (3 duplexes, each controlled by separate relay) |
| Standard level AC Surge Protection : | Merit Class (sacrificial) |
| Spike Protection Mode : | Line to neutral, zero ground leakage |
| Max Continuous Operating Voltage : | 130V RMS |
| Max Clamp Voltage : | 500 Volts Peak |
| Peak Impulse Current : | 12,000 Amps |
| Energy Rating (2 X 820μS) : | 225 Joules |
| AC Filtering : | Standard level Pi LCR Filter |
| Noise Attenuation : | >26dB, 100 Khz to 1 MHz |
| Operating Temperature Range : | 5C (40F) to 40C (105F) degrees |
| Humidity Range : | <90% rH (Relative Humidity) |
| Rocker Switch : | Front panel, Sequence (ON, OFF) |
| Thermal Circuit Breaker : | Front panel, push to reset |
| Front Panel Indicators : | Delay 1, Delay 2, Delay 3, Power, Protection OK |
| Rear Panel DIP Switches : | 12V Mode On/Off, GND Mode On, Momentary/Maintained |
| Potentiometer : | Rear panel, time calibration fine tune delay adjust |
| Remote Terminal : | +5-30VDC In, 12VDC (12mA) Out |
| Remote Terminal : | Phoenix type 4-Pin Connector with Screw terminals; +12V, STAT, REM, GND (Class 2 Wiring) |
| Dimensions : | 19"L x 8.75"D x 1.75"H – ANSI 1RU |
| Weight : | 7 lbs. |
| Power Consumption : | 5 Watts |
| Safety Agency : | C/CSA/US |
